Alpha Cantilever Sliding Gate
The Alpha gate combines optimum quality and security. Strong and clever, this smoothly running gate is available with a variety of infill options, including chain-link and welded wire.
The Alpha Cantilever Sliding Gate
The Alpha Gate, manufactured with an internal tensioned aluminum beam, is known for its engineered strength and durability. Wallace Perimeter Security has designed the chain-linked Alpha Gate to provide strength, security and protection in high traffic commercial applications.
The modular aluminum gate is powered by our innovative Kinetic motor. This motor is a key component, with its rack and pinion drive, providing a smooth and quiet operation. The variable-speed drive maximizes the gate hardware life, eliminating the instant start-and-stop motions of traditional, constant-speed motors.
- Rack and pinion drive
- Concealed nylon rollers
- Anti-climb top rail
- Commercial facilities
- Water treatment facilities
- Public transportation
- Traffic lights (bi-directional)
- Thru-beam safety photo cell
- Strobe light
- Vehicle detector loops/relays
- Cold-weather kit
|Technical Data||Alpha Specification|
|Infill Options||Chain link, Welded wire|
|Opening Speed||1' per second or 2' per second|
|Finish||Hot dip galvanized/ mill 1 finish aluminum, Powder coat options|
|Power Requirements||Voltage 115-230 V, Frequency 50-60 HZ, Current 15 AMP dedicated circuits|
ASTM F2200-02 compliant, UL 325 listed (class 1, 2, 3 & 4)
* 1 foot high (3 rows) barbed wire comes standard on all height and width combinations.
Word .doc versions of specifications and ACAD for specifiers available upon request.
- Alpha Sliding Gate - Brochure (PDF 0.6MB)
- Alpha Sliding Gate - Specifications (PDF 91KB)
- Alpha Sliding Gate - Drawing (PDF 0.7MB)
- Alpha Sliding Gate - Double Drawing (PDF 1.4MB)
- Alpha Installation Manual (PDF 2.6MB)
- Alpha Sliding Gate- CAD Drawing 1 of 5 (DWG 2.5MB)
- Alpha Sliding Gate - CAD Drawing 2 of 5 (DWG 0.6MB)
- Alpha Sliding Gate - CAD Drawing 3 of 5 (DWG 0.7MB)
- Alpha Sliding Gate - CAD Drawing 4 of 5 (DWG 2.3MB)
- Alpha Sliding Gate - CAD Drawing 5 of 5 (DWG 4.8MB)
Alpha Gate Videos
Alpha Gate withstands ramming attack.
Wallace Perimeter Security Alpha Gate -Cantilever Sliding Gate
The Alpha gate is designed to close single openings of up to 80 feet and the system is UL 325 listed. The modular construction allows for efficient delivery time and ensures that it is easy to unload on site. The gate comes with mounting posts and all required hardware. The Alpha gate stands out from other sliding gates with its integrated rack and pinion drive.
