UniFence is a cost-effective solution for a wide variety of applications.  Every intersecting point between the “U” profile and the wire bars is welded together, making it stronger and more secure.  This line of UniFence provides an attractive fencing option with good visibility.



  • See-through panels
  • Simple and cost effective installation
  • Versatile post and flange system
  • Brackets and hardware for all installations

Recommended Application

  • Industrial applications
  • Housing projects
  • Health care/research facilities
  • Overpasses and parking facilities

Technical Specifications

Technical Data UniFence Specification
Gauge of Wire Horizontal Wire and Vertical Wire .196” DIA (5 mm)
Mesh Opening 2.12”X 7 7/8” X 15 ¾” (54 mm x 200 mm x 400 mm)
Standard Height  4', 6', 8' (1245 mm. 1778 mm, 2464 mm)
Standard Length 8’3” (2510 mm)
Finish Pre-galvanized polyester powder coated
Options Various cap styles, rectangle and round post options
